Drihten Technology is a leading Crane Load Limiter Manufacturers in Pune. Our Inclinometers, also called Tilt Sensors, ensure precise overload prevention. We are the reputed suppliers of Crane Load Limiter in Pune with eight years of engineering innovations. As such, you may trust us in terms of durability, compliance and timely responsiveness.
Our Crane Load Limiters are rated on 360 Degree conical-axis detection, have relay alerts built-in and can be installed with around-the-clock ease (plug and play). Consequently, they integrate seamlessly with your EOT cranes, mobile cranes, and hoist systems.
We have expertise in industrial controllers and customized safety solutions. Our Load Limiters help you avoid costly downtime by preventing overloads. They find use in material-handling cranes, construction sites, and port terminals. To date, we have empowered over 50 clients across steel mills, power plants, and airports. Contact us - Drihten Technology is your top Crane Load Limiter Manufacturers in Pune and Crane Load Limiter Suppliers in Pune.
A Crane Load Limiter is a safety device that stops a crane from lifting loads beyond its rated capacity. It constantly measures load, boom angle, and radius to calculate real-time stress. Our units comply with DGMS load-radius norms under BIS Scheme-X and carry CE, ATEX, ISO 13849, and ISO 9001 certifications. Thus, they meet both Indian and international safety standards.
Crane Load Limiter is a safety device which is used to limit the loads that a crane can lift and is not sure that only the rated load will be lifted by the crane. It functions by constantly checking the load, the boom angle and radius to measure real time stress. In addition, it meets the DGMS and BIS norms besides CE,ATEX, ISO 13849 and ISO 9001 certification. These instruments explore load cells, angle sensors and pressure transducers so as to examine diverse loads ranging between 0.1 and 200 tonnes. Moreover, it is provided with set-points that could be adjusted, a 360 detection angle, several output options, and is reliable between -20 o C to 70 o C with IP65 protection. Several variations are available as compact Chain Hoist Limiters, which are used on small cranes, LMIs, used on mobile or tower cranes, and PLC-based limiters which are found in automated yards. These are widely used in EOT, mobile, tower, and marine cranes to ensure overload safety. Finally, the limiter works by combining load and angle data to trigger alarms or cut power instantly when limits are breached.
| Specification | Details |
|---|---|
| Measurement Principle | Load cells, angle sensors, and pressure transducers |
| Load Capacity Range | 0.1 to 200 tonnes |
| Set-Point Adjustment | Adjustable up to 110% of Safe Working Load |
| Detection Angle | 0° to 360° conical axis |
| Outputs | Relay contacts, analog (4–20 mA), digital (Modbus RTU) |
| Operating Temperature | –20 °C to 70 °C |
| Enclosure Protection | IP65 |
| Power Supply | 24 V DC |
Our Crane Load Limiters combine load cell data with inclinometer readings. First, load cells measure tension on the hoist line. Next, the inclinometer senses boom angle relative to gravity. A microcontroller calculates the actual load moment using both inputs. Finally, if limits are exceeded, a relay contact cuts power or triggers an alarm. This ensures immediate, automatic overload prevention.
To order, email info@drihtentechnology.com or call +91 73787 11885. All units undergo factory calibration as per NABL standards. They comply with: BIS Scheme-X (DGMS Load-Radius), PESO for explosive-atmosphere zones, CE & ATEX for European safety directives, ISO 13849 & ISO 9001 for functional safety and quality. Visit us at 5th Floor, Vision Flora Unit, Siddhivinayak, Pune 411027 for on-site demos.
Due to such benefits, we are the Leading Crane Load Limiter Manufacturers in Pune and Crane Load Limiter Suppliers in Pune.
Drihten Technology is your trusted manufacturer, supplier, and exporter of Crane Load Limiters in Pune. We deliver turnkey safety solutions worldwide, backed by full technical support and warranty. Get Your Quote Today - reach out to our team and safeguard your operations against overload risks.
Yes. Our PLC-based models offer Modbus RTU connectivity for seamless integration
We recommend annual calibration under NABL standards to ensure accuracy
The device retains set-point data and resumes protection upon power restoration.
A: Absolutely. Engineering staff has the capabilities to customize drop relays logic and alarm levels to suit your requirements
